สายมัลติคอร์ YSLY-OZ 2 x 0.5 sq.mm #10001YSLY

Name: YSLY-OZ 2 x 0.5 sq.mm Flexible Control Cable, Oil-Resistant #10001YSLY
Brand: HELUKABEL
SKU: 10001YSLY

รหัสสินค้า: 10001YSLY

สอบถามราคา

สอบถามสต็อก

รายละเอียดสินค้า

Part no.	Type	No.cores x cross-sec. mm²	Outer Ø approx. mm	Weight approx kg / km	Part no.	Type	No.cores x cross-sec. mm²	Outer Ø approx. mm	Weight approx kg / km
10001YSLY	YSLY-OZ	2X0,5	4.8	40	10047YSLY	YSLY-JZ	18G0,75	12.2	257
10002YSLY	YSLY-JZ	3G0,5	5.1	46	10060YSLY	YSLY-OZ	2X1	5.6	60
10004YSLY	YSLY-JZ	4G0,5	5.5	56	10061YSLY	YSLY-JZ	3G1	6.1	72
10006YSLY	YSLY-JZ	5G0,5	6.2	65	10063YSLY	YSLY-JZ	4G1	6.6	86
10008YSLY	YSLY-JZ	6G0,5	6.7	75	10065YSLY	YSLY-JZ	5G1	7.5	104
10009YSLY	YSLY-JZ	7G0,5	6.7	80	10067YSLY	YSLY-JZ	6G1	8.1	125
10011YSLY	YSLY-JZ	8G0,5	7.4	97	10068YSLY	YSLY-JZ	7G1	8.1	141
10012YSLY	YSLY-JZ	10G0,5	8.6	116	10070YSLY	YSLY-JZ	8G1	9.0	175
10013YSLY	YSLY-JZ	12G0,5	9.1	135	10071YSLY	YSLY-JZ	9G1	9.8	200
10015YSLY	YSLY-JZ	14G0,5	9.5	150	10180YSLY	YSLY-JZ	10G1	10.6	217
10183YSLY	YSLY-JZ	16G0,5	10.0	175	10072YSLY	YSLY-JZ	12G1	10.9	230
10016YSLY	YSLY-JZ	18G0,5	10.7	196	10074YSLY	YSLY-JZ	14G1	11.5	271
10030YSLY	YSLY-OZ	2X0,75	5.3	46	10075YSLY	YSLY-JZ	16G1	12.3	300
10031YSLY	YSLY-JZ	3G0,75	5.6	54	10076YSLY	YSLY-JZ	18G1	12.9	343
10033YSLY	YSLY-JZ	4G0,75	6.3	66	10090YSLY	YSLY-OZ	2X1,5	6.4	70
10035YSLY	YSLY-JZ	5G0,75	6.9	80	10091YSLY	YSLY-JZ	3G1,5	6.8	90
10037YSLY	YSLY-JZ	6G0,75	7.7	99	10093YSLY	YSLY-JZ	4G1,5	7.6	109
10038YSLY	YSLY-JZ	7G0,75	7.7	110	10095YSLY	YSLY-JZ	5G1,5	8.3	131
10040YSLY	YSLY-JZ	8G0,75	8.3	130	10097YSLY	YSLY-JZ	6G1,5	9.2	157
10041YSLY	YSLY-JZ	9G0,75	9.1	153	10098YSLY	YSLY-JZ	7G1,5	9.2	184
10042YSLY	YSLY-JZ	10G0,75	9.8	162	10100YSLY	YSLY-JZ	8G1,5	10.1	216
10043YSLY	YSLY-JZ	12G0,75	10.1	179	10101YSLY	YSLY-JZ	9G1,5	11.1	259
10045YSLY	YSLY-JZ	14G0,75	10.8	214	10181YSLY	YSLY-JZ	10G1,5	12.0	275
10046YSLY	YSLY-JZ	15G0,75	11.4	218	10102YSLY	YSLY-JZ	11G1,5	12.0	300

Part no.	Type	No.cores x cross-sec. mm²	Outer Ø approx. mm	Weight approx kg / km	Part no.	Type	No.cores x cross-sec. mm²	Outer Ø approx. mm	Weight approx kg / km
10103YSLY	YSLY-JZ	12G1,5	12.4	309	10141YSLY	YSLY-JZ	3G4	9.7	230
10105YSLY	YSLY-JZ	14G1,5	13.0	345	10142YSLY	YSLY-JZ	4G4	10.8	295
10106YSLY	YSLY-JZ	16G1,5	13.9	230	10143YSLY	YSLY-JZ	5G4	12.1	361
10107YSLY	YSLY-JZ	18G1,5	14.8	259	10144YSLY	YSLY-JZ	7G4	13.4	458
10120YSLY	YSLY-OZ	2X2,5	7.8	112	10145YSLY	YSLY-JZ	8G4	14.7	590
10121YSLY	YSLY-JZ	3G2,5	8.3	148	10549YSLY	YSLY-JZ	10G4	17.6	687
10123YSLY	YSLY-JZ	4G2,5	9.2	178	10146YSLY	YSLY-JZ	12G4	18.2	790
10125YSLY	YSLY-JZ	5G2,5	10.1	221	10147YSLY	YSLY-JZ	3G6	11.9	355
10127YSLY	YSLY-JZ	7G2,5	11.2	306	10148YSLY	YSLY-JZ	4G6	13.2	424
10129YSLY	YSLY-JZ	8G2,5	12.3	363	10149YSLY	YSLY-JZ	5G6	14.7	525
10548YSLY	YSLY-JZ	10G2,5	14.8	429	10150YSLY	YSLY-JZ	7G6	16.2	625
10130YSLY	YSLY-JZ	12G2,5	15.3	498	10151YSLY	YSLY-JZ	3G10	14.8	540
10131YSLY	YSLY-JZ	14G2,5	16.2	569	10152YSLY	YSLY-JZ	4G10	16.4	701
10132YSLY	YSLY-JZ	18G2,5	18.2	764	10153YSLY	YSLY-JZ	5G10	18.3	858
10140YSLY	YSLY-OZ	2X4	9.2	195	10190YSLY	YSLY-JZ	3G16	18.4	827
