Omron G6D-F4B DC24V Terminal Block Relay 5A 24VDC

Omron G6D-F4B DC24V Terminal Block Relay 5A 24VDC

Name: Omron G6D-F4B DC24V Terminal Block Relay 5A 24VDC
Brand: Omron
SKU: G6D-F4B DC24
Price: 1300.00 THB
Availability: OutOfStock

Part no.: G6D-F4B DC24

฿1,300

Ask about stock

ยี่ห้อ : OMRON รุ่น G6D-F4B DC24 * เทอร์มินัลบล็อก * แรงดัน 24 V DC กระแส 5 A

Specifications

แบรนด์	OMRON
ประเภทสินค้า	เทอร์มินัลบล็อก
รหัสรุ่น	G6D-F4B DC24
ซีรีส์	G6D
แรงดัน	24 V DC
กระแส	5 A
รายละเอียดตามข้อมูลเดิม	Omron G6D-F4B DC24V Terminal Block Relay 5A 24VDC

Product details

last update: December 2, 2021

When your order, specify the rated voltage.

Main unit

Model with Push-In Plus technology

Mounted Relay type	Contact form	Model	Operation coil ratings
Mechanical Relay	SPST x 4 (1NO x 4)	G6D-F4PU	12 VDC
Mechanical Relay		G6D-F4PU	24 VDC
Power MOS FET relay		G3DZ-F4PU	12 VDC
Power MOS FET relay		G3DZ-F4PU	24 VDC

Model with Screw Terminal

Mounted Relay type	Contact form	Model	Operation coil ratings
Mechanical Relay models	SPST x 4 (1NO x 4)	G6D-F4B	12 VDC
Mechanical Relay models		G6D-F4B	24 VDC
Power MOS FET relay		G3DZ-F4B	12 VDC
Power MOS FET relay		G3DZ-F4B	24 VDC

Accessories (Order Separately)

Replacement Relay

Applicable Terminal Relay Model	Model	Operation coil ratings
G6D-F4PU/G6D-F4B	G6D-1A-ASI	12 VDC
G6D-F4PU/G6D-F4B	G6D-1A-ASI	24 VDC
G3DZ-F4PU/G3DZ-F4B	G3DZ-2R6PL	12 VDC
G3DZ-F4PU/G3DZ-F4B	G3DZ-2R6PL	24 VDC

Connection socket (single sales available)

G6D-F4PU/G3DZ-F4PU (Model with Push-In Plus technology)

Model	Operation coil ratings
P6DF-F4PU	12 VDC
P6DF-F4PU	24 VDC

G6D-F4B/G3DZ-F4B (Models with Screw terminal)

Model	Operation coil ratings
P6DF-F4B	12 VDC
P6DF-F4B	24 VDC

Note: 1. Connection socket P6DF-F4B as a single part is not certified by safety standards individually.
2. Single socket which does not mount a relay (with terminal cover)
3. Only the terminal cover is also available separately.
Model: G6D-4-C, Minimum order (quantity): 10

Short Bar (G6D-F4PU/G3DZ-F4PU (Model with Push-In Plus technology))

Pitch	Applicable models	Number of poles	Color	*Model1**	Maximum carry current
7.75 mm	G6D-F4PU G3DZ-F4PU P6DF-F4PU	2	Red (R) Blue (S) Yellow (Y)	PYDN-7.75-020[]	20 A
		3		PYDN-7.75-030[]
		4		PYDN-7.75-040[]
		20		PYDN-7.75-200[]

Note: Use the Short Bars for crossover wiring within one Socket or between Sockets.
*1. Replace the box ([]) in the model number with the code for the covering color. Selection of the box ([]): R=Red, S=Blue, Y=Yellow
